Edge Round 12'' LED Flush Mount
MODEL: EGRF12
- LIGHT SOURCE: Integrated LED
- DIAMETER: 12''
- HEIGHT: 0.664''
- EXTENDS: 0.664''
- VOLTAGE: 120V, 277V
- WATTAGE: 22W
- CRI: 90
- SOURCE LUMENS: 2200
- DELIVERED LUMENS: 1694
- COLOR TEMPERATURE: 2700K/3000K/3500K/4000K/5000K
- DIMMING TYPE: Not Dimmable, TRIAC/ELV, 1-10V
- FINISH OPTIONS: White, Black, Satin Nickel
- DIFFUSER: Frosted
- DIFFUSER MATERIAL: Acrylic
- WARRANTY: 5 Year Limited
Thin Profile LED round ceiling light with edge-lit panel for wide, even light distribution. Adjustable CCT 2700/3000/3500/4000/5000K. White acrylic diffuser. Available in three sizes and finishes. Optional battery back-up available for 8in & 12in. sizes. Conversion kits available for 4in. and 6in, ceiling cans.
| Item Number | Finish | CCT | Voltage | Certifications & Features |
|---|---|---|---|---|
| EGRF-BB12 | White | 120V | Wet Rated, Battery Backup, cETLus | |
| EGRF-BB12PAN | White | cETLus | ||
| EGRF12LAJD1BK | Black | 2700K/3000K/3500K/4000K/5000K | 120V | Title 24, Wet Rated, 3-in-1 CCT, Dimmable, cETLus, FCC |
| EGRF12LAJD1SN | Satin Nickel | 2700K/3000K/3500K/4000K/5000K | 120V | Title 24, Wet Rated, 5-in-1 CCT, Dimmable, cETLus, FCC |
| EGRF12LAJD1WH | White | 2700K/3000K/3500K/4000K/5000K | 120V | Title 24, Wet Rated, 5-in-1 CCT, Dimmable, cETLus, FCC |
| EGRF12LAJD3BK | Black | 2700K/3000K/3500K/4000K/5000K | 277V | Title 24, 5-in-1 CCT, Dimmable, cETLus |
| EGRF12LAJD3WH | White | 2700K/3000K/3500K/4000K/5000K | 277V | Title 24, 5-in-1 CCT, Dimmable, cETLus |
| EGRF12LAJD5BK | Black | 2700K/3000K/3500K/4000K/5000K | 120V | Title 24, Wet Rated, 5-in-1 CCT, cETLus |
| EGRF12LAJD5WH | White | 2700K/3000K/3500K/4000K/5000K | 120V | Title 24, Wet Rated, 5-in-1 CCT, cETLus |
Title 24
Wet Rated
5-in-1 CCT
3-in-1 CCT
Dimmable
Battery Backup
*Some certifications and features may vary by SKU. Please refer to ordering information section for differences between item numbers.
